Fortacedx K200 Infinity Fully Automated Chemistry Analyzer

Fortace Dx K200 is an AKD automatic chemistry analyzer which is capable of examining more than 34 parameters with accurate and stable precision with an automatic examination speed of 200 tests/hour, with economical use of water, reagents and samples.

Dimension

720*450*550 mm

Weight

50 Kg

Reagent position

40 (20 large, 20 small)

Cuvettes

50 Cuvettes, semi-permanent UV special plastic

Input

AC 100-240V, 50/60Hz; 350 VA

Light source

halogen tungsten lamp 12V 20W

Working environment

"Temperature: 10-30° Reaction temperature: 37°"

FEATURE	BENEFIT
Equipped with 40 reagent positions (20 large and 20 small).	Equipped with a barcode reading feature on reagents to make it easier to record reagents.
Has a speed of 200 tests/hour.	Can increase the effectiveness of the laboratory in establishing a diagnosis.
Water consumption below 1.8L/hour.	It uses relatively little water so it can save water usage.
It has 8 wavelengths for checking different parameters.	8 waves for reading different parameters namely: 340nm, 405nm, 450nm, 510nm, 546nm, 578nm, 630nm, 679nm.
Maximum test time is 14 minutes.	With fast and automatic inspection times, it can streamline sample processing time by operators.
Has an FMSS (full-sealed matrix spectrometric system) filter.	Minimizes the occurrence of fungal contamination on the optical part (detector).
It has dimensions of 720 x 450 x 550 mm and weighs 50 kg.	Quite large dimensions, with large sizes and dimensions the test runs stably (avoiding vibrations and interference from the environment).
Can check more than 34 parameters.	Can measure parameters: ALT, AST, APL, GGT, TP, Alb, TBIL, DBIL, LDH, CK, Ck-MB, α-HBDH, CHO, TG, HDL-C, LDL-C, Apo A1, Apo B, Lp(α), BUN, CRE, UA, CO2-CP, AMS, LIP, GLU, HbA1C, IhA, IgG, IgM, C3, C4, CRP, Alcohol, etc.
Economical consumption of reagent (min reaction volume: 160 µL) and wash solution (60 µL/wash).	Saves on the use of reagents and wash solutions.
