Metabolic Disease State

Sinocare iCARE-2100 Multi Function Analyzer

4153

Introducing our state-of-the-art, fully automated diagnostic solution, designed to maximize efficiency in modern laboratory environments where space is limited. Featuring a fully automatic liquid-phase reaction system, it ensures user-friendly operation and compatibility with reagent kits from the same manufacturer. With its advanced automation and efficiency, this solution consistently delivers reliable result.

Variant

Sinocare iCARE-2100 Multi Function Analyzer

Sinocare iCARE-2100 HbA1c Reagent Kit

Sinocare iCARE-2100 Liver Function Reagen Kit (ALT/AST/TB/ALB)

Sinocare iCARE-2100 Renal Function Reagen Kit (Urea/Creatinine/Uric Acid)

Sinocare iCARE-2100 C Reactive Protein (CRP) Reagen Kit

Sinocare iCARE-2100 Lipid Profile Reagent Kit (TC/TG/HDL-C/LDL-C)

Sinocare iCARE-2100 Microalbumin / Creatinine Reagent Kit

Dimension

445x293x 308.6 (mm)

Weight

<15 Kg

Output

100-240 V AC, 50/60 Hz, 130 V

Communication Interface

Wi-Fi, RS232, RJ45, USB

Display

9.7 inc, touch screen

Printer

Built in Thermal printer

Operational Temperature

37 °C ± 5 °C

Measuring System

Light transmission system, fluoresence system, light reflection system

Data Storage

80.000 sample test, 10.000 QC test

Language

Simple English and Mandarin

FEATURE	BENEFIT
Dimensions and weight: 445 x 293 x 308.6 (mm)	Compact and lightweight, suitable for small laboratories with limited space.
Lightweight (<15 Kg)	A compact instrument that does not require large storage space.
Equipped with 37 parameters in 16 separate cartridges (panel) types	Enhances equipment procurement efficiency
Can store up to 90,000 tests (80.000 tests and 10.000 QC)	Facilitates tracking of measurement history, divided into two types: Sample and QC
Fast Measurement Time: 3-15 minutes	Quick detection meets customer satisfaction and institutional target times for delivering results.
Equipped with a thermal printer	Data interpretation becomes easier
Touch screen with large font size	Comfortable to use, avoiding reading errors
Connected to LIS and HIS	Data transfer becomes easier
Works automatically	User-friendly, saves usage time
Simple English and Mandarin language	Uses simple English and Mandarin, making it easy for users to understand.
Noise ≤65 decibels	Operates quietly, allowing for better concentration during work.
CE certified	The instrument is recognized and used internationally.
ISO 13485 certified.	The instrument is standardized for Medical Device manufacturing certification
Flexible, can measure 2 different panels simultaneously	Enhances operator time efficiency.
Supports various sample types (Whole Blood, Plasma, Serum, Urine)	Provides flexibility according to user needs.
