Sinocare PCH-100 HbA1c Analyzer

Metabolic Disease State

ICSIN00211

The Portable Glycated Hemoglobin Analyzer offers fast test results, reflecting glycemic control over the past 2 to 3 months using the boric acid affinity chromatography method. It is manufactured according to NGSP standards. PT Isotekindo Intertama is the official distributor of Sinocare PCH-100 HbA1c Analyzers, registered with the Indonesian Ministry of Health.

Variant

Sinocare HbA1c Reagent Kit

Dimensions

250x 235 x 126 (mm)

Display

4.3 inch LCD touch screen, 480 x 272 pixels

Weight

<3.5 Kg

Operating Temperature

15 °C - 35 °C

Tool Storage Temperature

20 °C - 55 °C

Printer

Built In thermal printer

Language

English / Simplified Chinese

Memory capacity

1.000 tests, 200 QC tests

Power

12V, 2A

Reagent Kit

HbA1c Reagent Kit made by Changsha Sinocare Inc

Method

Boric acid chromatography

Sample Volume

5 µl

Sample

capillary blood (fresh) & fresh venous blood (EDTA, NaF & heparin tubes)

Measuring Range

4.0% - 15.0%

Hematocrit Range

30 - 60%

Measurement Time

3.5 minutes

Precision

Coefficient of variation (CV) 8%

Accuracy

Relative deviation ±10%

Display

NGSP (National Glycohaemoglobin Standarization Program) units (%), IFCC (International Federation of Chemical Chemistry and laboratory medicine) units (mmol/mol)


FEATURE	BENEFIT
Dimensions size 250 x 235 x 126 (cm) , Weight <1.3 kg	Is a compact & lightweight instrument even for small labs with limited space
High-tech, wide, and compact monitor screen measuring 4.3-inch touch screen, 480x272 MP with simple English and Mandarin	Able to convey important & clear information to provide reliable results with minimum post-analytic errors
Connect with LIS (Laboratorium Information System)	Allows to connect with external instruments and ensures data security to meet audit & accreditation requirements with voice prompt
Equipped with thermal printer	Easy to interpret data in hard file form
Equipped with voice guidance (voice prompt)	Easy to use and minimizes errors when taking measurements
Storage Capacity 1.000 data samples, 200 QC data	Large memory capacity ensures customers have patient medical records, and also meets quality control requirements
Measurement time 3.5 minutes	Fast measurement times make operators work more efficiently
The detection system uses the boric acid affinity chromatography method	Currently standardized and has a good correlation with HPLC, making it suitable for clinical monitoring
Performance For HbA1c: Linearity: 4% - 15%, Linear correlation coefficient r 0.98 Accuracy: relative deviation within ±10%	Ensure that the equipment complies with the quality standards that have been set
